VRC-C 450 Trend
- Up to 90% heat recovery efficiency
- Compact and discrete ceiling installation
- Convenient operation with WiFi & My Stiebel App functionality via WLAN module
- Easy to clean and replace filters, ensuring optimal hygiene
- CO2 & indoor air quality monitoring
- Whisper quiet Operation
Product Overview
High-Performance Ventilation for Modern Buildings.
The VRC-C 450 Trend uses advanced heat recovery technology to reclaim warmth from outgoing air and transfer it to incoming fresh air. This process significantly reduces heating energy requirements while ensuring consistent indoor air quality year-round. The unit features balanced supply and extract airflow, integrated frost protection, and multiple ventilation modes to suit daily living, holiday periods, or peak humidity events. Designed for quiet, reliable operation, the system supports demand-controlled ventilation and can be operated via a wall-mounted controller or remotely using an optional WLAN module and smartphone app. With intelligent airflow control and flexible installation options, the VRC-C 450 Trend is ideal for energy-efficient residential buildings.
Product Details
The VRC-C 450 Trend is equipped with a cross-counter current heat exchanger, allowing a large proportion of heat from extracted air to be recovered before it exits the building. Separate supply and extract air fans ensure controlled airflow to living spaces while removing air from kitchens, bathrooms, and other high-moisture areas. Multiple operating modes are available, including reduced, standard, intensive, and humidity-protection ventilation, enabling the system to adapt to changing indoor conditions. Integrated constant airflow control maintains stable ventilation performance regardless of duct pressure. For colder climates, the unit includes intelligent frost protection, with the option to add an electric preheating coil to safeguard the heat exchanger during low outdoor temperatures. In warmer months, bypass functionality allows cooler night air to be drawn in for passive cooling. User control is simple and intuitive via the supplied programming unit, with real-time status displays, scheduling, and filter change notifications. Optional WLAN connectivity enables remote monitoring and control through the MyStiebel app. The VRC-C 450 Trend is designed for installation below the ceiling or wall-mounted (model dependent) and includes easily accessible filters and components for straightforward maintenance.
Technical Data
| Model number | VRC-C 450 Trend |
| Max. heat recovery | 90% |
| Air flow volume | 100 - 450 m3/h |
| Available ext pressure at max flow | 200 Pa |
| Sound power level | 45 dB(A) |
| IP Rating | IP22 |
| Electrical connection | 1/N/PE ~ 230V 50Hz |
| Filter class | ePM1 >50% (F7) | ISO coarse >65% (G4), (E12 optional) |
| Height | 280mm |
| Width | 590mm |
| Length | 1413mm |
| Air duct connection | DN180 |
| Condensate drain | 32mm |
| Weight |
48 kg |
| Type of installation | Ceiling |
Downloads
FAQ
Discover more about your heat recovery ventilation (HRV) system with our comprehensive FAQ. We've gathered the most common queries and provided detailed answers to help you maximize its efficiency and performance. Learn more by visiting our HRV FAQ page.
Visit our HRV FAQ page
